Narrow Bandpass Filter

Name: Narrow Bandpass Filter
Brand: ECOPTIK INDUSTRIAL PTE.LTD.

Narrowband filter is a special type of bandpass filter, but its performance requirements are more extreme and precise. It only allows light within a very narrow wavelength range to pass through, while strongly blocking all light outside of that range. Applied to fluorescence microscopy, astrophotography, Raman spectroscopy, flow cytometry, fluorescence detection and biosensing, laser cleaning and fluorescence excitation.

Contact

Features of Narrow Bandpass Filter

Bandwidth refers to the distance between two positions in the passband whose transmittance is half of the peak transmittanceThe above six parameters must be taken into account in the use and selection of narrow-band filters. Different performance indexes require different manufacturing costs of filters.

Specification of Narrow Bandpass Filter

Material	Optical glass BK7/ Fused silica
Surface quality	40/20, 20/10
Thickness range	0.5mm-5.0mm or upon the customer's request
FWHM	20nm, 30nm, 40nm, 50nm, 60nm or upon the customer's request
Wavelength range	340nm, 380nm, 405nm, 450nm, 492nm, 510nm, 546nm, 578nm, 600nm, 620nm, 630nm, 650nm, 850nm, 805nm, 940nm, 1064nm
OD	OD3, OD4, OD5
Dimension	3mm-200mm
